Wrist Strap Tester, Battery Powered, TT-WST200

ESD Wrist Strap Tester - One Button - Battery Operated - TT-WST200

The wrist strap tester ensures that basic ESD protection is met by quickly and accurately measuring the resistance of the wrist strap system and signally a pass or fail. A test voltage of 9 volts DC, the unit is specially designed to test without harm to the operator. The wrist strap tester verifies that a continuous grounding path between a wrist band and coil cord by indicating three levels of resistance: "HI", "LO" and "OK" with an easy to read LED light and an audible alarm. Test parameters are factory set to pass 800K - 10M.

Meets or exceeds requirements of ANSI ESD-S20.20 and the recommendations of ESD 4.1.

WRIST STRAP TESTER FEATURES
•  One button test of wrist straps
•  Audible and visual alarms
•  Compatible with standard single wire wrist straps
•  Factory calibrated: no adjustments or annual recalibration
•  Portable and battery operated

WRIST STRAP SPECIFICATIONS
•  Dimensions: 3.5"H x 2.75"W x 1.25"D
•  Weight: 5.4 oz
•  Test Voltage: Regulated 9 volts DC
•  Temperature: Operating 10C to 40C
                        Storage: -15C to 60C
•  Relative Humidity: 0% to 90% (non-condensing)
•  Accuracy +/- 5%
•  Operating voltage: >6.5 volts to <9 volts
•  Features: Battery low indicator
•  Power Input: 120VAC-60hz
•  Power Output: 12VDC, 200mA
•  Adjustment: No adjustments required
•  Alarm Indications
    Level    Display    Resistance  Alarm
    OK       Green      >800K          No
    LO        Red         <800K          Yes
    HI         Red         >10M           Yes

Product Code: TT-WST200   Wrist Strap Tester

ORDER WRIST STRAP TESTER
To order the wrist strap tester, click tab above, call customer service at (303)752-0076 or email sale@kfqizhongji.com

Shipping Instructions: The wrist strap tester can ship via UPS or FedEx. The order ships collect or prepay and add to the invoice. If shipping collect, add your freight account number in the “Comments Box” when checking out. Customer is responsible for the freight charge.

In addition to wrist strap testers, we also offer a variety of other ESD Products including ESD Mats, Ionization Equipment and ESD Tape and Dispensers.
